Carbon Full Spectrum LED panels
Experience ROE Visual's full-spectrum LED technology based on our advanced RGB-CA and RGB-W Carbon CB5MKII LED panels.
ROE Visual's full-spectrum LED panels offer advanced solutions for achieving realistic on-camera results, particularly for accurately rendering skin tones and improving reflections. By incorporating additional emitters beyond the standard RGB format, these panels extend the spectral bandwidth, deliver higher brightness, and provide more accurate color representation. This results in a greater tonal and color rendering range compared to typical RGB panels.
Unprecedented Color Accuracy
RGB+ panels bridge the gaps between the standard RGB red, green, and blue colors found in traditional LED packages. These panels offers a wider spectrum in individual color segments, delivering enhanced spectral bandwidth and cinematic color fidelity. This makes them ideal for lighting talents or set elements in virtual production environments, where realism is crucial.
Both RGB-W and RGB-CA versions are available in the Carbon CB5MKII platform. The RGB-W version is designed for indoor use only, while the RGB-CA version offers a waterproof solution, making it suitable for outdoor applications.
LED Processing for Full Spectrum LED Panels
The Carbon MarkII Full Spectrum Key Features
All-In-One Solution
The Carbon MarkII panel offers improved integration, the frame now adapts to Air Frame. The panel can curve in both convex and concave directions. Its flexible design is suited for outdoor applications.
Hanging Configuration
Stacking Configuration
Air Frame
Lightweight and integrated wind bracing.
Dolly
Contributing to cost savings in shipping, truck load weight and air freight costs when compared to conventional touring frames.
Specs
- Title
- Pixel Pitch
- LED Configuration
- Max Brightness Calibrated
- Panel Dimension
- Panel Resolution (H x V)
- Weight Per Panel
- Power Consumption Max/Average
- BTU Max/Average
- Transparency
- Serviceability
- Curving (Concave & Convex)
- Viewing Angle Vertical
- Viewing Angle Horizontal
- Refresh Rate
- Gray Scale
- Scan Ratio
- Operational Temp/Humidity
- Storage Temp/Humidity
- IP Rating
- Certifications
- Max. Hanging
- Max. Stacking
- CB3MKⅡ
- 3.75mm
- SMD 1515 Black
- 4500nits
- 600mm x 1200mm x 79mm
23.6” x 47.2” x 3.1” - 160 x 320
- 14.4kg | 31.7lbs
- 600W / 300W
- 2050 / 945
- Solid
- Front / Rear
- Concave 15° ~ Convex 10°
- 110°
- 140°
- 3840Hz
- 16bit
- 1/10
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP65
- CE, ETL, FCC, UKCA, SAA
- 12 panels
- 5 panels
- CB3MKⅡ Half
- 3.75mm
- SMD 1515 Black
- 4500nits
- 600mm x 600mm x 79mm
23.6” x 23.6” x 3.1” - 160 x 160
- 7.8kg | 17.2lbs
- 290W / 145W
- 990 / 455
- Solid
- Front / Rear
- Concave 15° ~ Convex 10°
- 110°
- 140°
- 3840Hz
- 16bit
- 1/10
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP65
- CE, ETL, FCC, UKCA, SAA
- 24 panels
- 10 panels
- CB5MKⅡ
- 5.77mm
- SMD 1921 White
- 6000nits
- 600mm x 1200mm x 79mm
23.6” x 47.2” x 3.1” - 104 x 208
- 13.6kg | 29.9lbs
- 480W / 240W
- 1640 / 755
- Solid
- Front / Rear
- Concave 15° ~ Convex 10°
- 110°
- 140°
- 7680Hz
- 16bit
- 1/4
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP65
- CE, ETL, FCC, UKCA, SAA
- 12 panels
- 5 panels
- CB5MKⅡ Half
- 5.77mm
- SMD 1921 White
- 6000nits
- 600mm x 600mm x 79mm
23.6” x 23.6” x 3.1” - 104 x 104
- 7.2kg | 15.8lbs
- 250W / 125W
- 850 / 395
- Solid
- Front / Rear
- Concave 15° ~ Convex 10°
- 110°
- 140°
- 7680Hz
- 16bit
- 1/4
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP65
- CE, ETL, FCC, UKCA, SAA
- 24 panels
- 10 panels
- CB8MKⅡ
- 8.33mm
- SMD 1921 White
- 6000nits
- 600mm x 1200mm x 79mm
23.6” x 47.2” x 3.1” - 72 x 144
- 11kg | 24.3lbs
- 530W / 260W
- 1810 / 835
- 23%
- Front / Rear
- Concave 15° ~ Convex 10°
- 110°
- 140°
- 7680Hz
- 16bit
- 1/4
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP65
- CE, ETL, FCC, UKCA, SAA
- 12 panels
- 5 panels
- CB8MKⅡ Half
- 8.33mm
- SMD 1921 White
- 6000nits
- 600mm x 600mm x 79mm
23.6” x 23.6” x 3.1” - 72 x 72
- 6kg | 13.2lbs
- 260W / 130W
- 890 / 410
- 23%
- Front / Rear
- Concave 15° ~ Convex 10°
- 110°
- 140°
- 7680Hz
- 16bit
- 1/4
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP65
- CE, ETL, FCC, UKCA, SAA
- 24 panels
- 10 panels
Downloads
Application Fields
- Touring and Festivals
- Outdoor events
- Sports Events
- Virtual Production Ceiling
