Black Pearl
LED with perfect on-camera performance
Black Pearl is a high-performance, broadcast grade, HD-LED panel. Specially designed for use in film studios and virtual production applications it offers cutting-edge LED design and technology.
Black Pearl is available in two versions, the BP2 and BP2V2 both with a 2.8mm pixel pitch. With its high frame rate, high refresh rate and low scan lines it is perfect for studio or broadcast work. Its on-camera performance is unrivaled.
Fast and Easy Set-up
Intelligent Module and Easy Maintenance
Superb Visuals
High Power Supply Efficiency
Flexible Installation Options
Black Pearl BP2V2
The Film-Centric LED panel
The BP2V2 offers the trusted performance of the Black Pearl BP2 in an updated version with high-speed components and true-to-content color representation. It results in an identical, perfect on-camera performance as the BP2, adding quicker and easier camera set up and handling. Its on-camera performance is unrivaled, ideal for film applications.
Black Pearl Key Features
Specs
- Title
- Pixel Pitch
- LED Configuration
- Max Brightness Calibrated
- Panel Dimension
- Panel Resolution (H x V)
- Weight Per Panel
- Power Consumption Max/Average
- BTU Max/Average
- Transparency
- Serviceability
- Curving (Concave & Convex)
- Viewing Angle Vertical
- Viewing Angle Horizontal
- Refresh Rate
- Gray Scale
- Scan Ratio
- Operational Temp/Humidity
- Storage Temp/Humidity
- IP Rating
- Certifications
- Max. Hanging
- Max. Stacking
- BP2V2
- 2.84mm
- SMD 1515 Black
- 1500nits
- 500mm x 500mm x 90mm
19.69” x 19.69” x 3.54” - 176 x 176
- 9.35kg | 20.61lbs
- 190W / 95W
- 630 / 300
- Solid
- Front
- Concave 10° ~ Convex 0°
- 140°
- 140°
- 7680Hz
- 16bit
- 1/8
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, ETL, FCC, WEEE
- 20 panels
- 12 panels
Application Fields
- Broadcast
- Film Production
- Virtual Event Stages
- Indoor Events
- Theatre
"Since the technique of LED virtual production was explored and the first pioneering steps were taken, both Unreal Engine and ROE Visual have been involved. It really takes a team of passionate experts to make this technology work, because so many aspects are at play. More importantly though is the amazing working relationship we have with ROE Visual, so together we can experiment, discover and shift the boundaries ever further”.
Epic Games Ben Kidd
