Vanish
Transparent LED in a large panel design
The Vanish LED panel is a large frame, indoor transparent LED panel. With a transparency from 35% to 62%, this LED panel offers outstanding performance in indoor environments through its high brightness and excellent viewing angles. Smaller LED and PCB design add improved transparency.
High Transparent LED panel
Modular Design
Lightweight Design
High Brightness
Easy to Install Vanish Key Features
Hanging and Stacking
Curving Options
Downloads
Specs
V5S MKⅡ
V8S MKⅡ (White LED)
- Title
- Pixel Pitch
- LED Configuration
- Max Brightness Calibrated
- Panel Dimension
- Panel Resolution (H x V)
- Weight Per Panel
- Power Consumption Max/Average
- BTU Max/Average
- Transparency
- Serviceability
- Curving (Concave & Convex)
- Viewing Angle Vertical
- Viewing Angle Horizontal
- Refresh Rate
- Gray Scale
- Scan Ratio
- Operational Temp/Humidity
- Storage Temp/Humidity
- IP Rating
- Certifications
- Max. Hanging
- Max. Stacking
- V5S MKⅡ
- 5.6mm
- SMD 1515 Black
- 2000nits
- 1000mm x 1000mm x 67mm
39.4” x 39.4” x 2.6” - 176 x 176
- 10.9kg | 24.03lbs
- 420W / 210W
- 1430 / 655
- 35%
- Front
- Concave 10° ~ Convex 10°
- 140°
- 160°
- 3840Hz
- 14bit
- 1/11
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, ETL, FCC, SAA
- 15 panels
- 6 panels
- V8S MKⅡ (White LED)
- 8.9mm
- SMD 1515 White
- 3500nits
- 1000mm x 1000mm x 67mm
39.4” x 39.4” x 2.6” - 112 x 112
- 9.6kg | 21.16lbs
- 460W / 230W
- 1570 / 720
- 62%
- Front
- Concave 10° ~ Convex 10°
- 140°
- 160°
- 3840Hz
- 14bit
- 1/4
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, ETL, FCC, SAA
- 15 panels
- 6 panels
Application Fields
- Touring
- Concert
- Events
