Meru

Ready to Fit Any Space

Meet Meru, the versatile LED solution for indoor AV Integration. Built with a precision-engineered frame and equipped with an energy-efficient power supply, Meru delivers exceptional visual quality while minimizing operational demands, making it an ideal choice for a wide range of permanent installations where both form and function are essential.

Available in two panel sizes — 500×500mm and 500×1000mm — and with pixel pitches of 1.9mm and 2.6mm, Meru offers a versatile option for today’s most common viewing distances. Its compatibility with standard mounting systems allows effortless integration into public spaces such as airports, shopping malls, corporate lobbies, and broadcast studios, while maximizing spatial efficiency.

Combining stunning visuals with long-term efficiency, Meru lowers operating costs through reduced power consumption and extended lifespan. Designed to captivate audiences and support a wide range of environments, Meru helps your installations stand out with brilliance and reliability.

Download brochure

ROE Visual Meru display

Stunning Visuals and Performance

Meru features an ultra-high 7680Hz refresh rate, minimizing scan lines for exceptional in-camera performance. With wide DCI-P3 color gamut coverage, it delivers vibrant, accurate colors and lifelike detail. Whether viewed directly or through the lens, Meru stands out in any environment.

Meru struction of seemless assembly

Precise Seamless Assembly

Meru delivers exceptional screen flatness with structural tolerances of just 0.05mm, while its wall-mounted frame and modular design enable fast installation, and a micro-adjustment system ensures precise panel alignment for a seamless finish.

Meru with power redundancy

Energy Efficiency

Designed for reliability, Meru comes with optional dual power redundancy, ensuring uninterrupted performance in critical applications. Pairing its operational stability with energy-efficient engineering, Meru will reduce your overall operating costs.

Easy Front Access

Easy Front Access

Meru’s slim 68–73mm profile meets ADA standards and supports full front maintenance for easy servicing. Magnetic modules allow for quick installation and swaps, reducing downtime.

Meru Key Features

EMC Class B Certification
Indoor Use
Easy Installation and Maintenance
Sleek Wall-mount Design
High-precision Structure
Meru for airport
Meru to public spaces
Where you could see Meru

Downloads

Designed to Go Anywhere

Compatible with standard mounting systems, Meru’s clean, wall-mounted design integrates seamlessly into modern interiors of any size or complexity.

Meru with EMC-Class B report

EMC-Class B Certified

With EMC Class B certification, Meru operates safely even in complex environments such as airports, control rooms, and other mission-critical spaces where stability is non-negotiable.

Specs

Download All Specs
MR1.9
MR1.9 Half
MR2.6
MR2.6 Half
  • Title
  • Pixel Pitch
  • LED Configuration
  • Max Brightness Calibrated
  • Panel Dimension
  • Panel Resolution (H x V)
  • Weight Per Panel
  • Power Consumption Max/Average
  • BTU Max/Average
  • Transparency
  • Serviceability
  • Viewing Angle Vertical
  • Viewing Angle Horizontal
  • Refresh Rate
  • Gray Scale
  • Scan Ratio
  • Operational Temp/Humidity
  • Storage Temp/Humidity
  • IP Rating
  • Certifications
  • MR1.9
  • 1.9mm
  • 1000nits
  • 500mm x 1000mm x 48mm
    19.69” x 39.37” x 1.89”
  • 256 x 512
  • 14.8kg | 32.6lbs
  • 220W / 110W
  • 760 / 380
  • Solid
  • Front
  • 160°
  • 160°
  • 7680Hz
  • 15bit
  • -20°C ~ 45°C, 10% ~ 90% RH
    -4°F ~ 113°F, 10% ~ 90% RH
  • -40°C ~ 60°C, 10% ~ 90% RH
    -40°F ~ 140°F, 10% ~ 90% RH
  • IP40
  • CE, FCC, ETL, UKCA, RoHS, WEEE
  • MR1.9 Half
  • 1.9mm
  • 1000nits
  • 500mm x 500mm x 48mm
    19.69” x 19.69” x 1.89”
  • 256 x 256
  • 7.4kg | 16.3lbs
  • 110W / 55W
  • 380 / 190
  • Solid
  • Front
  • 160°
  • 160°
  • 7680Hz
  • 15bit
  • -20°C ~ 45°C, 10% ~ 90% RH
    -4°F ~ 113°F, 10% ~ 90% RH
  • -40°C ~ 60°C, 10% ~ 90% RH
    -40°F ~ 140°F, 10% ~ 90% RH
  • IP40
  • CE, FCC, ETL, UKCA, RoHS, WEEE
  • MR2.6
  • 2.6mm
  • 1200nits
  • 500mm x 1000mm x 48mm
    19.69” x 39.37” x 1.89”
  • 192 x 384
  • 14.8kg | 32.6lbs
  • 280W / 140W
  • 960 / 480
  • Solid
  • Front
  • 160°
  • 160°
  • 7680Hz
  • 15bit
  • -20°C ~ 45°C, 10% ~ 90% RH
    -4°F ~ 113°F, 10% ~ 90% RH
  • -40°C ~ 60°C, 10% ~ 90% RH
    -40°F ~ 140°F, 10% ~ 90% RH
  • IP40
  • CE, FCC, ETL, UKCA, RoHS, WEEE
  • MR2.6 Half
  • 2.6mm
  • 1200nits
  • 500mm x 500mm x 48mm
    19.69” x 19.69” x 1.89”
  • 192 x 192
  • 7.4kg | 16.3lbs
  • 140W / 70W
  • 480 / 240
  • Solid
  • Front
  • 160°
  • 160°
  • 7680Hz
  • 15bit
  • -20°C ~ 45°C, 10% ~ 90% RH
    -4°F ~ 113°F, 10% ~ 90% RH
  • -40°C ~ 60°C, 10% ~ 90% RH
    -40°F ~ 140°F, 10% ~ 90% RH
  • IP40
  • CE, FCC, ETL, UKCA, RoHS, WEEE
All specification values given are per panel. The specifications are for reference only, actual values may vary. The max. hanging amount is only valid when official ROE Visual hardware parts are used. The safety factor is 8. Climbing is only allowed if stated in the panel manual and only following the rules given therein. The max. stacking amount is only valid when official ROE Visual hardware parts are used and when sufficient ballast is applied – following the rules as stated in the panel manual and/or structural report.
Compare products
Comparison
<< product.title >>
  • Title
meru application

Application Fields

  • Public Spaces
  • Corporate
  • Broadcast
