Black Marble BM5

Brilliant LED at your feet

ROE Visual’s Red Dot award-winning Black Marble LED floor panel brings creativity to your feet. Available with a high-contrast glass or matte or mirror finish, these floor panels are suited for a wide range of creative uses, such as broadcast, live music, corporate events, xR Stages and a variety of other applications.

Request a Demo

ROE Visual Smart Design - Enhanced Features

Smart Design - Enhanced Features

The Black Marble BM5 panels measure 600 x 600 mm and have a 5.769mm pixel pitch, these futures make it possible to combine the BM5 LED floor with other LED modules, keeping the same resolution. The Black Marble BM5 offers enhanced options, like an anti-moiré finish for better on-camera performance and a wide viewing angle. Optional integrated interactivity is available on the BM5i LED panels.

ROE Visual Fashionable Finishes

Fashionable Finishes

The Black Marble panels are deliverable in various high-end finishes, suited for different environments and applications. The Deep Black, Mirror and Matte finishes all have a strong, anti-scratch surface.
The Matte finish offers a non-reflective LED panel, ideal for broadcast or xR Stages the Deep Black finish offers a stylish and glossy panel with a true, deep back color. Ideal for a high-tech design look and feel for retail, architectural and exhibition applications.

ROE Visual Fast and Easy Set-up

Builds fast and easy

The Black Marble LED floor is easy to build, the support frames can be installed using a minimum number of tools. Once you have leveled out your floor frames, you can just add the LED panels on top.

ROE Visual Versatile System

Support Options

The Black Marble support options are easy and quick to install and offer a versatile support system that can be used to create floors, multi-level floor or stages and stairs. This thought-through integrated system is very easy to install and leaves room for maximum creativity, while guaranteeing structural stability and safety at all times. The LED floor has a loading capacity of 2000 kg.

ROE Visual Support Frame

Triangular panels

The Black Marble LED floor system includes triangular LED panels adding extra design options. A round LED floor is easily configured using the standard square and triangular Black Marble BM4 LED panels.

Downloads

Black Marble 5 Key Features

Top access for easy module maintenance
IP65 rating, outdoor use and wet cleaning to keep your floor in pristine condition.
Safety first, max. loading 2000kg/m2
Safe access - anti-skidding surface on all LED panels
Magnetic Modules, easy module swapping
Versatile system - Stairs and multilevel stages

Specs

Download All Specs
BM2i-Matte
BM5-PC-Matte
BM5-Glass
  • Title
  • Pixel Pitch
  • LED Configuration
  • Max Brightness Calibrated
  • Panel Dimension
  • Panel Resolution (H x V)
  • Weight Per Panel
  • Power Consumption Max/Average
  • BTU Max/Average
  • Transparency
  • Serviceability
  • Viewing Angle Vertical
  • Viewing Angle Horizontal
  • Refresh Rate
  • Gray Scale
  • Scan Ratio
  • Operational Temp/Humidity
  • Storage Temp/Humidity
  • IP Rating
  • Certifications
  • BM2i-Matte
  • 2.82mm
  • SMD 1515 Black
  • 800nits
  • 609.6mm x 609.6mm x 133mm
    24” x 24” x 5.2”
  • 216 x 216
  • 18.6kg | 41lbs
  • 310W / 155W
  • 1060 / 490
  • Solid
  • Front
  • n.a.°
  • 140°
  • 7680Hz
  • 16bit
  • 1/12
  • -20°C ~ 45°C, 10% ~ 90% RH
    -4°F ~ 113°F, 10% ~ 90% RH
  • -40°C ~ 60°C, 10% ~ 90% RH
    -40°F ~ 140°F, 10% ~ 90% RH
  • IP65
  • CE, ETL, FCC, WEEE
  • BM5-PC-Matte
  • 5.7692mm
  • SMD 1921 White
  • 2000nits
  • 600mm x 600mm x 103mm
    23.6” x 23.6” x 4.1”
  • 104 x 104
  • 13.5kg | 29.76lbs
  • 270W / 135W
  • 920 / 420
  • Solid
  • Front
  • n.a.
  • 140°
  • 3840Hz
  • 14bit
  • 1/4
  • -20°C ~ 45°C, 10% ~ 90% RH
    -4°F ~ 113°F, 10% ~ 90% RH
  • -40°C ~ 60°C, 10% ~ 90% RH
    -40°F ~ 140°F, 10% ~ 90% RH
  • IP65
  • CE, ETL, FCC, WEEE
  • BM5-Glass
  • 5.7692mm
  • SMD 1921 White
  • 800nits
  • 600mm x 600mm x 110mm
    23.6” x 23.6” x 4.3”
  • 104 x 104
  • 18.3kg | 40.35lbs
  • 270W / 135W
  • 920 / 420
  • Solid
  • Front
  • n.a.
  • 140°
  • 3840Hz
  • 14bit
  • 1/4
  • -20°C ~ 45°C, 10% ~ 90% RH
    -4°F ~ 113°F, 10% ~ 90% RH
  • -40°C ~ 60°C, 10% ~ 90% RH
    -40°F ~ 140°F, 10% ~ 90% RH
  • IP65
  • CE, ETL
Compare products
Comparison
<< product.title >>
  • Title
Black Marble LED Panels

Application Fields

  • Events
  • Broadcast
  • Concerts
  • Carshows
  • Hospitality

Accessories

Brompton

Flightcase

Power Cable 10m

Power Cable 0.75m
